Sale! Red neon DPST switch as used in our powerboards.Specifications:Switch TypeRockerPoles / Contacts2 poleThrows / Positions1posPole Throw TypeDPSTCycle Life10000 cyclesContact Resistance20mSwitch FunctionLocking On/OffInsulation Resistance100MSwitch Connectio
Unconditional Satisfaction GuaranteeNo Shipping Fees Above 302 Months to Decide. Returns Simplified.Red neon DPST switch as used in our powerboards.
Specifications:
| Switch Type | Rocker |
| Poles / Contacts | 2 pole |
| Throws / Positions | 1pos |
| Pole Throw Type | DPST |
| Cycle Life | 10000 cycles |
| Contact Resistance | 20m |
| Switch Function | Locking On/Off |
| Insulation Resistance | 100M |
| Switch Connection | Solder Legs |
| Dielectric Strength | 1000V |
| Switch Colour Coded | Red |
| Mechanism Material | Plastic |
| Mounting Method | Panel,Front of Panel |
| Attachment / Securing Method | Snap-in |
| Square Mount Hole Width | 12mm |
| Square Mount Hole Height | 20mm |
| AC Voltage rating | 240V |
| AC current rating | 10A |
| Nominal Voltage | 250V |
| Type | Neon |
| Illumination Colour | Red |
| Connection | Spade Terminals |
| Length | 21mm |
| Width | 15mm |
| Height | 27mm |
Cost - $25
