Hobbyist multimeters provide exceptional value for money, and good features for a range of applications.
This practical multimeter measures both DC and AC voltages and currents. The default autoranging setting automatically selects the best range for your measurements. If a different range is preferred, simply switch it to manual. A built-in buzzer and LED warning light alert you to low resistance, detected voltage and live wires. In low light conditions you can activate the 10 second backlight to view measurements. Use the data hold button to lock them on screen for data capture and analysis.
ForMore infoon Digital Multimeters.
Specifications:
| Optical Sensor |
No |
| Measures dwell |
No |
| Count / Maximum Reading |
2000 count |
| True RMS |
No |
| Autorange |
Yes |
| Measures duty cycle |
No |
| Safety Rating Cat |
Cat III |
| Safety Rating Max Volt |
600V |
| DC Voltage Accuracy |
0.8% |
| DC Voltage Ranges |
200mV,2V,20V,600V |
| DC Current Ranges |
200A,2mA,20mA,200mA,10A |
| DC Current Accuracy |
3% |
| AC Voltage Accuracy |
1% |
| AC Voltage Ranges |
200V,2mV,20mV,200V,600V |
| AC Current Ranges |
200A,2mA,20mA,200mA,10A |
| AC Current Accuracy |
3% |
| Continuity indicator |
On Panel |
| Continuity buzzer |
Yes |
| Resistance Ranges |
200,2k,20k,200k,2M |
| Resistance Accuracy |
1.5% |
| Probe Type |
High Grade Meter Probes |
| Connection to meter |
Shrouded 4mm Banana Plug |
| Probe rating voltage |
600V |
| Probe safety rating |
Cat III |
| Measures transistor |
No |
| Carry Case Included |
No |
| Foldout Stand |
Yes |
| Casing |
Plastic |
| Meter Input Impedence |
10M |
| Measures diode |
Yes |
| Input Protection Fuse |
500mA,10A |
| Led Indicator Display |
No |
| Length |
144mm |
| Weight |
200g |
| Width |
70mm |
| Height |
32mm |
| Size / Shape |
AAA |
| Battery quantity |
2pc |
| Batteries included |
Yes |
| Batteries can be replaced by user |
Yes |
| Battery used for |
Main Product |
| Compartment location |
Back |
| How is battery compartment kept closed |
Screw |
| Batteries can be replaced |
Yes |
| Size / Shape |
AAA |
| Display Type |
LCD |
| Display Backlight |
LED Backlit |
