Often in a workbench environment you dont need massive amounts of power, and your huge unit is under-utilised. This slimline power supply provides up to 80W of power, still plenty of grunt for many tasks. It provides constant current and constant voltage options. Simply select your power range, then adjust the controls to obtain your desired outputs. Ranges available are 0-16V @ 0-5A, 0-27VDC @ 0-3A, and 0-36V @ 0-2.2A. Output is provided via banana sockets which will accept insulated banana plugs. A powerful, compact unit for your workbench or mobile toolkit. Includes banana to alligator clamp leads.
Features: Constant current / constant voltage options Up to 5A current Compact design Input Voltage: 100-240VAC @ 50/60Hz Output Voltage: 0-16VDC 0-5A (Max), 0-27VDC @ 0-3A (Max), 0-36VDC @ 0-2.2A (Max Output Power: 80W Max.
Specifications:
| Width |
53mm |
| Height |
138mm |
| Depth |
300mm |
| Weight |
886g |
| Output Connection |
Banana 4mm (standard) |
| Number of Outputs |
1pc |
| Ripple Voltage |
30mV |
| Type of Power Supply |
Laboratory |
| Voltage Display |
Yes |
| Regulation Type |
SMPS |
| Current Display |
Yes |
| AC Voltage rating |
240V |
| AC Frequency |
50Hz |
| Rated for AU Mains |
Yes |
| Mains Max Current |
1.1A |
| Mains Voltage Range |
100V-240V |
| Frequency |
50Hz-60Hz |
| Rated for US Mains |
Yes |
| Auto-select mains voltage |
Yes |
